Winado 9500 BTU 24 SEER2 Ceiling Concealed Ducted Air Conditioner with Heat Pump 230V
$695.99
This 9500 BTU ducted inverter heat pump split air conditioner from ROVSUN obtains Energy Star, AHRI and ETL certifications with 24 SEER2 high energy efficiency to save up to 40 percent power consumption. It realizes fast cooling, heating and dehumidification for spaces up to 400 square feet, supporting three control options of wired control panel, handheld remote and mobile APP. The unit runs as low as 39 decibels under mute mode with balanced air output, equipped with matching installation fittings and suitable for all-year temperature control in residential rooms and light commercial offices.
9500 BTU cooling and 95000 BTU heating capacity quickly regulates indoor temperature from 61 to 88 degree Fahrenheit, plus independent dehumidification function to satisfy various household and small-space usage requirements. Advanced inverter technology automatically changes compressor rotating speed following indoor temperature fluctuation, hits 24 SEER2 high efficiency and reduces electricity cost by maximum 40 percent for long-term cost saving. Optimized air supply structure creates even room airflow, mute mode works quietly at 39 decibels to build tranquil indoor environment ideal for bedrooms and office areas. Multi-way intelligent control includes wired wall controller, remote control and mobile APP, users can set regular temperature schedules and adjust operating status remotely from any location. Keep the air conditioner upright for 24 hours before professional licensed HVAC installation; package contains standard 16.4 feet copper tubing and drain hoses, while power cord needs to be prepared separately after receiving both indoor and outdoor packages.
General |
|||
|---|---|---|---|
Color/Finish Family |
White |
Manufacturer Color/Finish |
White |
Type |
Quick connect (DIY) |
Application |
Heating/Cooling |
Control Type |
Digital |
Filter Type |
Mesh |
Mounting Location |
Wall |
Refrigerant Type |
R-454B |
Number of Tons |
.75 |
||
Dimensions |
|||
|---|---|---|---|
Air Handler Depth (Inches) |
17.72 |
Air Handler Height (Inches) |
7.87 |
Air Handler Width (Inches) |
27.56 |
Compressor Depth (Inches) |
12 |
Compressor Height (Inches) |
21.61 |
Compressor Width (Inches) |
31.88 |
Cord Length (Feet) |
0 |
Depth (Inches) |
17.72 |
Height (Inches) |
7.87 |
Line-set Connection Size |
1/4-in x 3/8-in |
Line-set Length |
16-2/5-ft |
Maximum Coverage Area (Sq. Feet) |
400 |
Weight (lbs.) |
84.88 |
Width (Inches) |
27.56 |
Zone Capacity |
1 zone |
Amperage |
25 |
Features |
|||
|---|---|---|---|
24 Hour Timer |
Yes |
Auto Cool |
No |
Automatic Shut-Off |
Yes |
Cooling BTU Rating (BTU) |
9500 |
Decibel Rating (Highest Setting) |
43 |
Decibel Rating (Lowest Setting) |
39 |
Fan Only Option |
Yes |
Full Load Amperage Requirement (Amps) |
25 |
Heat Pump Included |
Yes |
Heating BTU Rating (BTU) |
9500 |
Hub Required |
No |
Low Voltage Compensation |
Yes |
Lowe’s Exclusive |
Yes |
Minimum Outdoor Temperature (Fahrenheit) |
-4 |
Multi-Directional Air Control |
Yes |
Noise Rating |
Quiet (45 decibels or below) |
Number of Speeds |
8 |
Oscillation |
Yes |
Overload Protection |
Yes |
Pre-Charged Line Set |
No |
Quiet Mode |
Yes |
Remote Control Included |
Yes |
Sleep Mode |
Yes |
Thermostat |
Yes |
Timer |
Yes |
Voltage (Volts) |
230 |
Compatibility |
|||
|---|---|---|---|
App Compatibility |
App required |
Bluetooth Compatibility |
No |
Smart Compatible |
Yes |
Wi-Fi Compatibility |
Yes |
Works with Amazon Alexa |
No |
Works with Android |
Yes |
Works with Apple HomeKit |
No |
Works with iOS |
Yes |
Works with SmartThings |
Yes |
Works with the Google Assistant |
Yes |
Warranty |
|||
|---|---|---|---|
Warranty |
60-day limited |
||
Certifications |
|||
|---|---|---|---|
AHRI Certified |
Yes |
CA Residents: Prop 65 Warning(s) |
No |
Energy Efficiency Ratio (E.E.R.) |
9.5 |
Safety Listing |
ETL safety listing |
Seasonal Energy Efficiency Ratio (SEER2) |
24 |
||
Miscellaneous |
|||
|---|---|---|---|
UNSPSC |
40101700 |
||
