Winado 9500 BTU 24 SEER2 Ceiling Concealed Ducted Air Conditioner with Heat Pump 230V

$695.99

Free Shipping Fast delivery within the US
Easy Returns 30-day hassle-free returns
Secure Checkout PayPal & Credit/Debit Cards
SKU: LW-5020034617 Category:
Description

This 9500 BTU ducted inverter heat pump split air conditioner from ROVSUN obtains Energy Star, AHRI and ETL certifications with 24 SEER2 high energy efficiency to save up to 40 percent power consumption. It realizes fast cooling, heating and dehumidification for spaces up to 400 square feet, supporting three control options of wired control panel, handheld remote and mobile APP. The unit runs as low as 39 decibels under mute mode with balanced air output, equipped with matching installation fittings and suitable for all-year temperature control in residential rooms and light commercial offices.

9500 BTU cooling and 95000 BTU heating capacity quickly regulates indoor temperature from 61 to 88 degree Fahrenheit, plus independent dehumidification function to satisfy various household and small-space usage requirements. Advanced inverter technology automatically changes compressor rotating speed following indoor temperature fluctuation, hits 24 SEER2 high efficiency and reduces electricity cost by maximum 40 percent for long-term cost saving. Optimized air supply structure creates even room airflow, mute mode works quietly at 39 decibels to build tranquil indoor environment ideal for bedrooms and office areas. Multi-way intelligent control includes wired wall controller, remote control and mobile APP, users can set regular temperature schedules and adjust operating status remotely from any location. Keep the air conditioner upright for 24 hours before professional licensed HVAC installation; package contains standard 16.4 feet copper tubing and drain hoses, while power cord needs to be prepared separately after receiving both indoor and outdoor packages.

Specifications
General
Color/Finish Family

White

Manufacturer Color/Finish

White

Type

Quick connect (DIY)

Application

Heating/Cooling

Control Type

Digital

Filter Type

Mesh

Mounting Location

Wall

Refrigerant Type

R-454B

Number of Tons

.75

Dimensions
Air Handler Depth (Inches)

17.72

Air Handler Height (Inches)

7.87

Air Handler Width (Inches)

27.56

Compressor Depth (Inches)

12

Compressor Height (Inches)

21.61

Compressor Width (Inches)

31.88

Cord Length (Feet)

0

Depth (Inches)

17.72

Height (Inches)

7.87

Line-set Connection Size

1/4-in x 3/8-in

Line-set Length

16-2/5-ft

Maximum Coverage Area (Sq. Feet)

400

Weight (lbs.)

84.88

Width (Inches)

27.56

Zone Capacity

1 zone

Amperage

25

Features
24 Hour Timer

Yes

Auto Cool

No

Automatic Shut-Off

Yes

Cooling BTU Rating (BTU)

9500

Decibel Rating (Highest Setting)

43

Decibel Rating (Lowest Setting)

39

Fan Only Option

Yes

Full Load Amperage Requirement (Amps)

25

Heat Pump Included

Yes

Heating BTU Rating (BTU)

9500

Hub Required

No

Low Voltage Compensation

Yes

Lowe’s Exclusive

Yes

Minimum Outdoor Temperature (Fahrenheit)

-4

Multi-Directional Air Control

Yes

Noise Rating

Quiet (45 decibels or below)

Number of Speeds

8

Oscillation

Yes

Overload Protection

Yes

Pre-Charged Line Set

No

Quiet Mode

Yes

Remote Control Included

Yes

Sleep Mode

Yes

Thermostat

Yes

Timer

Yes

Voltage (Volts)

230

Compatibility
App Compatibility

App required

Bluetooth Compatibility

No

Smart Compatible

Yes

Wi-Fi Compatibility

Yes

Works with Amazon Alexa

No

Works with Android

Yes

Works with Apple HomeKit

No

Works with iOS

Yes

Works with SmartThings

Yes

Works with the Google Assistant

Yes

Warranty
Warranty

60-day limited

Certifications
AHRI Certified

Yes

CA Residents: Prop 65 Warning(s)

No

Energy Efficiency Ratio (E.E.R.)

9.5

Safety Listing

ETL safety listing

Seasonal Energy Efficiency Ratio (SEER2)

24

Miscellaneous
UNSPSC

40101700
