Winado 18000 BTU 23 SEER2 Ceiling Concealed Ducted Air Conditioner with Heat Pump 230V
$1,016.99
This 17000 BTU ducted inverter heat pump split air conditioner from ROVSUN holds Energy Star, AHRI and ETL certifications with 23 SEER2 high energy efficiency to cut up to 40 percent electricity consumption. It realizes fast cooling and heating for spaces up to 1000 square feet alongside dehumidification function, supports wired panel, handheld remote and mobile APP three types of intelligent control, runs as low as 36 decibels under mute mode with even air output, equipped with complete installation accessories and applicable for year-round temperature regulation in residential rooms and light commercial offices.
17000 BTU rated cooling and 18000 BTU rated heating capacity enables quick indoor temperature adjustment within 61 to 88 degree Fahrenheit, with dehumidifying option to satisfy multi-scene demands for houses and small commercial spaces. Advanced inverter technology automatically regulates compressor rotating speed following indoor temperature fluctuation, reaching 23 SEER2 efficiency and saving as much as 40 percent power to reduce long-term electricity expenditure. Optimized airflow design delivers balanced room air circulation, operating noise falls to 36 decibels at mute setting to build quiet and cozy environment suitable for bedrooms and office rest areas. Three control solutions including wired indoor controller, physical remote and mobile APP allow parameter setup on site or remote anywhere, supporting customized temperature scheduling for convenient pre-set operation. Standard installation fittings of 16.4 feet copper piping and connecting accessories are contained in package; indoor unit needs upright placement for 24 hours before professional HVAC installation to guarantee stable running performance.
General |
|||
|---|---|---|---|
Color/Finish Family |
White |
Manufacturer Color/Finish |
White |
Type |
Quick connect (DIY) |
Application |
Heating/Cooling |
Control Type |
Digital |
Filter Type |
Mesh |
Mounting Location |
Wall |
Refrigerant Type |
R-454B |
Number of Tons |
1.5 |
||
Dimensions |
|||
|---|---|---|---|
Air Handler Depth (Inches) |
17.8 |
Air Handler Height (Inches) |
7.87 |
Air Handler Width (Inches) |
36.22 |
Compressor Depth (Inches) |
14.96 |
Compressor Height (Inches) |
27.52 |
Compressor Width (Inches) |
36.5 |
Cord Length (Feet) |
0 |
Depth (Inches) |
17.8 |
Height (Inches) |
7.87 |
Line-set Connection Size |
1/4-in x 1/2-in |
Line-set Length |
16-2/5-ft |
Maximum Coverage Area (Sq. Feet) |
1000 |
Weight (lbs.) |
123.46 |
Width (Inches) |
36.22 |
Zone Capacity |
1 zone |
Amperage |
25 |
Features |
|||
|---|---|---|---|
24 Hour Timer |
Yes |
Auto Cool |
No |
Automatic Shut-Off |
Yes |
Cooling BTU Rating (BTU) |
18000 |
Decibel Rating (Highest Setting) |
41 |
Decibel Rating (Lowest Setting) |
36 |
Fan Only Option |
Yes |
Full Load Amperage Requirement (Amps) |
25 |
Heat Pump Included |
Yes |
Heating BTU Rating (BTU) |
18000 |
Hub Required |
No |
Low Voltage Compensation |
Yes |
Lowe’s Exclusive |
Yes |
Minimum Outdoor Temperature (Fahrenheit) |
-4 |
Multi-Directional Air Control |
Yes |
Noise Rating |
Quiet (45 decibels or below) |
Number of Speeds |
8 |
Oscillation |
Yes |
Overload Protection |
Yes |
Pre-Charged Line Set |
No |
Quiet Mode |
Yes |
Remote Control Included |
Yes |
Sleep Mode |
Yes |
Thermostat |
Yes |
Timer |
Yes |
Voltage (Volts) |
230 |
Compatibility |
|||
|---|---|---|---|
App Compatibility |
App required |
Bluetooth Compatibility |
No |
Smart Compatible |
Yes |
Wi-Fi Compatibility |
Yes |
Works with Amazon Alexa |
No |
Works with Android |
Yes |
Works with Apple HomeKit |
No |
Works with iOS |
Yes |
Works with SmartThings |
Yes |
Works with the Google Assistant |
Yes |
Warranty |
|||
|---|---|---|---|
Warranty |
60-day limited |
||
Certifications |
|||
|---|---|---|---|
AHRI Certified |
Yes |
CA Residents: Prop 65 Warning(s) |
No |
Energy Efficiency Ratio (E.E.R.) |
9.5 |
Safety Listing |
ETL safety listing |
Seasonal Energy Efficiency Ratio (SEER2) |
23 |
||
Miscellaneous |
|||
|---|---|---|---|
UNSPSC |
40101700 |
||
