Description
SONAR:
- Crips, clear traditional sonar and brilliant ClearVü and SideVü scanning sonars to consistently display fish arches and clear pictures of objects, fish, and structures that pass below the boat
- High-contrast vivid scanning sonar color palettes make it easier than ever to distinguish targets and structure
NAVIGATION:
- Select chartplotters come with built-in Garmin Navionics+ cartography which includes a 1-year subscription for daily updates, depth range shading and more
- Improved position accuracy, particularly in areas where signals are reflected or weak, with multi-band GPS
- Chartplotters with built-in Garmin Navionics+ charts include downloadable Auto Guidance+ technology3 with the ActiveCaptain app
CONNECTIVITY:
- Integrated Wi-Fi connectivity pairs with Activecaptain® app
- Share info among compatible ECHOMAP UHD chartplotters, such as sonar, waypoints, and routes
ADDINTIONAL DETAILS:
- 7” chartplotter come bundled with a GT54 transducer
- ECHOMAP UHD2 wirelessly connects to your Force trolling motor to create and follow routes, navigate to waypoints, control speed, check battery life and more
- 1 MicroSD™ card; 32 GB Maximum size
Specifications
| Dimensions | 8.6″ x 5.6″ x 3.2″ (21.8 x 14.2 x 8.1 cm) |
|---|---|
| Input | Touchscreen with Keyed assist |
| Display Size | 6.1″ x 3.4″, 7.0″ (15.5 x 8.7 cm, 17.8 cm) |
| Display Resolution | 800 x 480 pixels |
| Weight | 2.2 lbs (1.0 kg) |
| Waterproof | IPX7 |
| Mounting options | Bail or Flush |
| Waypoints | 5,000 |
| Tracks | 50,000 |
| Navigation Routes | 100 |
| Receiver | 10 Hz |
| POWER INPUT | 9 to 18 |
| POWER OUTPUT | 500 W |
| CLEARVÜ | built-in 260/455/800/1000/1200 kHz |
| SIDEVÜ | built-in 260/455/800/1000/1200 kHz |
| TRADITIONAL SONAR (DUAL FREQUENCY/BEAM) | built-in (single channel CHIRP, 50/77/83/200 kHz, L, M, H CHIRP) |
Additional information
| Item |
Garmin ECHOMAP UHD2 73SV with GT54UHD-TM Transducer |
|---|
